WFC3 IR Grism¶
ABSCAL Example Notebook¶
This notebook will take you through the steps of downloading sample MAST data and running the WFC3 IR grism abscal scripts on that data.
Set up Python Environment¶
This step imports the python modules used by this script.
[1]:
import glob
import os
import numpy as np
import shutil
from astroquery.mast import Observations
from pathlib import Path
from tempfile import TemporaryDirectory
from abscal.wfc3.preprocess_table_create import populate_table
from abscal.wfc3.reduce_grism_coadd import coadd
from abscal.wfc3.reduce_grism_wavelength import wlmeas, wlmake
%matplotlib inline
work_dir = os.getcwd()
Matplotlib is building the font cache; this may take a moment.
Optional: Set up temporary directory for data¶
By default, notebooks store downloaded files (etc.) in the directory in which they are running. If you don’t wish to do this (or don’t have access to that directory), you can set up a temporary directory and store data in it.
[2]:
# Set this flag to True if you wish to use a temporary directory
use_temporary_dir = True
# Set this flag if you want to define a custom directory to work in
use_custom_dir = False
if use_temporary_dir:
data_dir = TemporaryDirectory()
os.chdir(data_dir.name)
work_dir = data_dir.name
if use_custom_dir:
work_dir = "/Users/york/Projects/abscal/examples/notebook_dev"
print("Storing data in {}".format(work_dir))
Storing data in /tmp/tmpr8lduj_p
Optional: Download input data from MAST¶
This notebook is designed to be run with any WFC3 IR grism data (although planetary nebula observations of a known target will be required for the wavelength steps). In order to simply see how these scripts work with example data, or to test their operation, you can use a set of example data.
The next cell defines a function that will download all non-HLA data from a specific HST observing program (i.e. data whose observation ID does not begin with “hst_”), and copy the downloaded files into a single directory (here, the same directory where the notebook is running). This function may be more generally useful for retrieving observations from MAST, and can be copied and used separately (or modified to suit) as long as the following import statements are included:
from astroquery.mast import Observations
import os
import shutil
The following cell will download two sets of example data (a flux calibration target and a planetary nebula target) from MAST. In particular, it will download program 15587 for flux calibration, and 13582 for planetary nebula data.
If you already have downloaded data with which you want to work, these cells can be skipped entirely.
[3]:
def download_mast_program(proposal_id, download_dir, skip_existing_files=True):
flux_table = Observations.query_criteria(proposal_id=proposal_id)
obs_mask = [x[:4] != 'hst_' for x in flux_table['obs_id']]
obs_filter = [id for id in flux_table['obs_id'] if id[:4] != 'hst_']
flux_table = flux_table[obs_mask]
obs_ids = flux_table['obsid']
if skip_existing_files:
i = 0
while i < len(obs_filter):
# This is an idiom for going through a list and potentially removing items from it. If you're going
# through a list in a for loop, the result of removing items from the list during the loop is not
# well-defined, so this method is used instead.
if len(glob.glob(os.path.join(download_dir, obs_filter[i]+"*"))) > 0:
obs_filter.remove(obs_filter[i])
else:
i += 1
data_products = Observations.get_product_list(obs_ids)
if len(data_products) > 0 and len(obs_filter) > 0:
manifest = Observations.download_products(data_products, download_dir=download_dir, extension=["fits"],
obs_id=obs_filter)
for file_name in manifest['Local Path']:
base_file = os.path.basename(file_name)
print("Copying {}".format(base_file))
shutil.copy(os.path.join(download_dir, file_name), os.path.join(download_dir, base_file))
[4]:
# Download the planetary nebula program
download_mast_program(13582, work_dir)
# Download the flux calibration program
download_mast_program(15587, work_dir)
